Guangzhou water treatment plant small to west Africa
- PRODUCT DETAIL
Guangzhou water treatment plant small to west Africa
1, the introduction of pure water equipment system
1). The equipment related to pure water equipment is automatically operated by liquid level interlocking, with automatic functions (automatic water production, automatic flushing, raw water shortage/water tank full water automatic shutdown, high and low pressure alarm, etc.).
2). The design of the actuator adopts standardized, generalized and systematic components, which is convenient for disassembly, replacement and cleaning of parts.
3). The system structure is compact and the floor space is small, which saves space.
4). The system has low energy consumption and effectively saves energy.
5). Long life of consumables and low cost of water production.
6). The system runs reliably, the water supply pipeline is closed, and the effluent water quality is stable.
7). Use materials that are non-polluting to water quality.
2, the scope of application of pure water equipment
Direct drinking water, industrial and mining enterprises, production water, electroplating industry water, battery water, chemical industry process water
4, can provide installation services;
5. one year warranty, lifetime maintenance
Model
TLW-500/1000/1500/2000L/3000L/5000L
Water sauce
Total dissolved solids content:TDS＜200ppm，water pressure:1.0-5.0kg/cm2,working temperature:25℃
power
AC220V/50HZ,AC380V/50HZ
Capacity(L)
150L/H
250L/H
500L/H
1000L/H
1500L/H
2000L/H
power（KW）
0.1-0.5
1.1-1.5
1.5-2.5
2.5-3.5
2.5-3.5
2.5-3.5
waterquality（μs/cm）
Conductivity15<μs/cm
Machine size（mm）
1200*580*1200
1500*550*1500
1800*800*1800
Floor area
8㎡about
10-12㎡about
12-15㎡about
weight（kg)
＜300KG
＜600KG
＜1000KG
Water application
Direct drinking water, industrial and mining enterprises, production water, electroplating industry water, battery water, chemical enterprise process water, medical pure water
Water tank
100L
250L
500L
1000L
1500L
2000L
